Specs
| 300 Gallon | 500 Gallon | 750 Gallon | 1250 Gallon |
|---|
| Vehicle Compatibility | ¾- or 1-Ton Pickup Truck | Dump Body, Flatbed, or 15,000+ GVWR Truck | Dump Body, Flatbed, or 15,000+ GVWR Truck | Dump Body, Flatbed, or 15,000+ GVWR Truck |
| Vehicle Compatibility | ¾- or 1-Ton Pickup Truck | Dump Body, Flatbed, or 15,000+ GVWR Truck | Dump Body, Flatbed, or 15,000+ GVWR Truck | Dump Body, Flatbed, or 15,000+ GVWR Truck |
| Tank Part Number | TSA-300 | TSA-500 | TSA-750 | TSA-1250 |
| Tank Part Number | TSA-300 | TSA-500 | TSA-750 | TSA-1250 |
| Approx. Weight (Empty) | 320 lb | 475 lb | 740 lb | 860 lb |
| Approx. Weight (Empty) | 145.2 kg | 215.5 kg | 335.7 kg | 390.1 kg |
| Overall Dimensions (w/pump) (LxWxH) | 101" x 54" x 42" | 112" x 59" x 54" | 118" x 75" x 55" | 119" x 85" x 73" |
| Overall Dimensions (w/pump) (LxWxH) | 256.5 cm x 137.2 cm x 106.7 cm | 284.5 cm x 149.9 cm x 137.2 cm | 299.7 cm x 190.5 cm x 139.7 cm | 302.3 cm x 215.9 cm x 185.4 cm |
| Capacity | 300 gal | 500 gal | 750 gal | 1,250 gal |
| Capacity | 1,135.6 L | 1,892.7 L | 2,839.1 L | 4,731.8 L |
| Suggested Gross Vehicle Weight Rating (GVWR) | 8,500 - 10,000 lb | 14,000 - 16,000 lb | 16,000 - 19,000 lb | 19,500 - 26,000 lb |
| Suggested Gross Vehicle Weight Rating (GVWR) | 3,855.5 - 4,535.9 kg | 6,350.3 - 7,257.5 kg | 7,257.5 - 8,845.1 kg | 8,845.1 - 11,793.4 kg |
| Vehicle Class | Class 2B | Class 4 | Class 5 | Class 6 |
| Vehicle Class | Class 2B | Class 4 | Class 5 | Class 6 |
| Pump Part Number | HFS-100-2, HFD-200EX or HFD-200HYD | HFS-100-2, HFD-200EX or HFD-200HYD | HFS-100-2, HFD-200EX or HFD-200HYD | HFS-100-2, HFD-200EX or HFD-200HYD |
| Pump Part Number | HFS-100-2, HFD-200EX or HFD-200HYD | HFS-100-2, HFD-200EX or HFD-200HYD | HFS-100-2, HFD-200EX or HFD-200HYD | HFS-100-2, HFD-200EX or HFD-200HYD |
| Gas Motor/Standard Control (HFS-100) | Manual Start 5.5 hp HONDA®/On-off 3-zone control | Manual Start 5.5 hp HONDA®/On-off 3-zone control | Manual Start 5.5 hp HONDA®/On-off 3-zone control | Manual Start 5.5 hp HONDA®/On-off 3-zone control |
| Gas Motor/Standard Control (HFS-100) | Manual Start 5.5 hp HONDA®/On-off 3-zone control | Manual Start 5.5 hp HONDA®/On-off 3-zone control | Manual Start 5.5 hp HONDA®/On-off 3-zone control | Manual Start 5.5 hp HONDA®/On-off 3-zone control |
| Gas Motor/Deluxe Control (HFD-200EX) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) |
| Gas Motor/Deluxe Control (HFD-200EX) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) | Electric Start 5.5 hp HONDA®/Automatic, 3-zone controlled flow (GPS optional) |
| Hydraulic Motor/Deluxe Control (HFD-200HYD) | Hydraulic with spool valve | Hydraulic with spool valve | Hydraulic with spool valve | Hydraulic with spool valve |
| Hydraulic Motor/Deluxe Control (HFD-200HYD) | Hydraulic with spool valve | Hydraulic with spool valve | Hydraulic with spool valve | Hydraulic with spool valve |
| Pump Frame | Powder coated steel with fork pockets | Powder coated steel with fork pockets | Powder coated steel with fork pockets | Powder coated steel with fork pockets |
| Pump Frame | Powder coated steel with fork pockets | Powder coated steel with fork pockets | Powder coated steel with fork pockets | Powder coated steel with fork pockets |
| Pump | 210 gpm Dry-Seal centrifugal circulation pump | 210 gpm Dry-Seal centrifugal circulation pump | 210 gpm Dry-Seal centrifugal circulation pump | 210 gpm Dry-Seal centrifugal circulation pump |
| Pump | 794.9 L/min Dry-Seal centrifugal circulation pump | 794.9 L/min Dry-Seal centrifugal circulation pump | 794.9 L/min Dry-Seal centrifugal circulation pump | 794.9 L/min Dry-Seal centrifugal circulation pump |
| Primary Valves | Electric ball valves | Electric ball valves | Electric ball valves | Electric ball valves |
| Primary Valves | Electric ball valves | Electric ball valves | Electric ball valves | Electric ball valves |
| Boom Part Number | PBA-300-1 | PBA-300-1 | PBA-300-1 | PBA-300-1 |
| Boom Part Number | PBA-300-1 | PBA-300-1 | PBA-300-1 | PBA-300-1 |
| Overall Width | 8' 2" | 8' 2" | 8' 2" | 8' 2" |
| Overall Width | 2.49 m | 2.49 m | 2.49 m | 2.49 m |
| Spray Width (boom only) | 8' | 8' | 8' | 8' |
| Spray Width (boom only) | 2.44 m | 2.44 m | 2.44 m | 2.44 m |
| Spray Width (w/ wing sprayer) | 24' | 24' | 24' | 24' |
| Spray Width (w/ wing sprayer) | 7.32 m | 7.32 m | 7.32 m | 7.32 m |
| Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles |
| Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles | Center Boom: 3 Triple Solid Stream Nozzles. Boom Ends: 2 Boomless Side Nozzles |
| Spraying Capacity | 10 to 60 gal/acre depending on vehicle speed | 10 to 60 gal/acre depending on vehicle speed | 10 to 60 gal/acre depending on vehicle speed | 10 to 60 gal/acre depending on vehicle speed |
| Spraying Capacity | 10 to 60 gal/acre depending on vehicle speed | 10 to 60 gal/acre depending on vehicle speed | 10 to 60 gal/acre depending on vehicle speed | 10 to 60 gal/acre depending on vehicle speed |
